Technical Parameters
Model | M32S | |
Print Head | Epson DX5/2 | |
Print Width | 3250mm | |
Media | PP self-adhesive vinyl, backlit film, photo paper, car sticker, reflective film , PVC cold lamination film,heat- transfer paper etc | |
Ink | Ink Type | Eco-solvent ink/Water-based ink |
Color | Four color(C/M/Y/K) | |
Ink Tank Volume | 1000ml tank for each color | |
Supply Type | Negative pressure CISS | |
Print Speed | Production Model | 44㎡/h |
Accuracy Mode | 38㎡/h | |
High Resolution Mode | 26㎡/h | |
Print Head Height | 2-3mm | |
Drying System | fans | |
Heating System | Front/back heating | |
Head Cleaning | auto cleaning | |
Automatic material receiving system | Standard | |
Platform Suction Regulation | Standard | |
Print Interface | network port print interface | |
Operating System | WinXP /Win7 | |
Printing Software | Maintop | |
Operating Environment | Best Operating temperature 15°C—30°C Relative humidity 40%—60% | |
Power Supply | AC—220V,50Hz/60Hz | |
Power(W) | 800W | |
Language | English/Chinese | |
Packing Size & Weight | 4900*1240*1580m, 650kg | |
3. Product configuration
(1) Large-capacity ink tan solves multiple ink refill problems
(2) HIWIN guide
(3) Chinese and English operation panel, switch easily.
(4) Universal wheel, easy to move.
(5) Standard automatic media-receiving system,external fan.
4. Product Application
(1) Outdoor adverting.
(2) Indoor decorative paintings.
5. Product Detail
6. Warranty and After-sales Service
<1>.1 Year Warranty for printer; 3 Years Warranty for borads; life-long online free tech support.
<2>.Instant online support service.
<3>.One to one professional technical free training.
