Macro Color 1.6m/5ft Eco Solvent Printer M16 is our most popular model since 2013.
M16 has gained good popularity among our domestic market and oversea dealers with it's fashionable outlook, stable performance, wide application range and cost effective features.
Main Features
Macro Color M16 is our most popular model since 2013.
1) Fashionable Black Master outlook and durable mechannical design
2) Epson DX5/DX11/5113 print heads for high resolution image output
3) Standard ICC file tested with different print head and our inks for best color performance
4) 1800mm large print size meet wide range of print jobs for your business
5) Easy for installation, use and maintain.
Model | M16S | ||||
Print Head | Epson DX5 | XP600 | Epson 4720 | Epson XP600 | |
Print Head Number | 1 | 2 | |||
Print resolution | 720dpi, 1080dpi, 1440dpi | ||||
Print Width | 1540mm | 1620mm | |||
Speed | Production Mode | 15.9㎡/h | 18.5㎡/h | 21.6㎡/h | 26.6㎡/h |
Accuracy Mode | 12.3㎡/h | 15.3㎡/h | 18.1㎡/h | 24.6㎡/h | |
High Resolution Mode | 8.2㎡/h | 12.8㎡/h | 15.6㎡/h | 18.6㎡/h | |
Ink | Ink Type | Eco solvent/ water-based ink | Eco solvent/ water-based ink | water-based ink | Eco solvent/ water-based ink |
Color | Four color(CMYK) | Double four color(CMYK) | |||
Ink Tank Volume | 1000ml tank for each color | ||||
Supply Type | Negative pressure continuous ink supply | ||||
Media | Water-based Media | PP self-adhesive vinyl, backlit film, photopaper, movable PP self-adhesive vinyl, photo cloth etc. | |||
Oily-based Media | photo paper , canvas ,car sticker, reflective film, PVC cold lamination film etc. | ||||
Heating System | Fore /back heating | ||||
Drying System | fans(optional) | ||||
Media Loading & Take up System | Standard | ||||
Cleaning System | Automaticcleaning | ||||
Data Transmission | Network port printing | ||||
Software | Maintop | ||||
Power Supply | 220V，50Hz/60Hz Operating temperature 15° C-30° C relative humidity 40-60% | ||||
Operation System | WinXP/Win7 | ||||
Machine Weight/ Size | 125±5%kg/2545×455×1300mm | 140±5%kg/2837×455×1300mm | |||
Package Size | 165±5%kg/2580×800×500mm | 185±5%kg/2870×820×500mm | |||
Application
(1) Indoor and outdoor advertising painting(Photo paper, PP paper, cold lamination film, adhesive, etc.)
(2) Wall paper production& Decorative paintings(Wallpaper substrate,canvas,non-woven fabric etc.)
(3) Outside car stickers
